Toa SC-615 Outdoor Horn Speaker 15Watts

The SC-615 is a compact, highly intelligible speaker suited to public address announcement applications. Its external speaker component finished with powder coating, and stainless steel bracket and screws ensure the unit’s weatherproof capability.

15W Input (mobile mount, 10W).
Low Impedance (8 Ω).
Stainless steel brackets and hardware.
Shock resistant aluminium oval horn.
Unobtrusive off-white colour.
Compliance with IP-65.

Specification
Rated Input 15W (mobile mount use, 10W)
Line Voltage n / a
Rated Impedance 8 Ω
Sound Pressure Level 112dB, 1W / 1m at 500 to 2,500 Hz peak level).
Frequency Response 280 ~ 12,500Hz
Sensitivity when used as Microphone (0 dB = 1 mW/10 dynes/cm 2) -22 dB at 1 kHz
IP Grade IP65
Polarity Hot; Black wire, com; White wire
Operating Temperature -20 ~ +55°C (must be free from dew condensation)
Finish Horn flare: Aluminum, off-white, powder coating / Reflector horn and rear cover: ABS resin, off-white / Bracket, Screws and bolts: Stainless steel / Speaker cable: Polyvinyl chloride insulated cabtyre cable (6 mm in diameter, 600 mm in length)
Dimensions 222 (W) x 179 (H) x 234 (D) mm
Weight 1.1 kg
Material Aluminium
Option Swivel bracket: YS-151S (Can be used instead of the supplied bracket.)
