SWP CHAOS Variable Shade 9/13 Welding & Grinding Helmet

The SWP Chaos Welding & Grinding Helmet offers medium range welding vision, ideal for TIG and Plasma Welding. With variable shading and fully adjustable sensitivity and delay features, it maximizes ADF filter and provides state-of-the-art shade 4 protection through new generation true colour technology. CE classified 1/1/1/2 for all types of welding.

Medium range welding vision
Working from 3 amps ideal for TIG and Plasma Welding
Variable shading to maximise the ADF filter and protection
State shade 4 due to the new generation true colour technology
Auto and manual shade settings
Fully adjustable sensitivity and delay optimises setting for all types of welding in MIG, TIG and Plasma
CE Classification: 1/1/1/2

Specifications
Filter Dimensions: 114mm x 133mm x 9.5mm
Viewing Area: 100mm x 83.4mm
CE Classification: 1/1/1/2
Sensors: 4
Auto Shade: Yes
Light Shade: 4
Dark State: Variable shade 5-9/9-13
Shade Control: Internal
Switching Time: 0.04ms(ANSI)
Sensitivity Control: Adjustable (Internal, Digital)
Delay Time Control: Adjustable 0.1-0.9S
Grinding Function: Yes – Digital Control
Low Battery Warning Indicator: Yes
Operation Temperature: -10°C -65°C
Storing Temperature: -20°C-85°C
Power Supply: Solar Cell, Replaceable Battery 1 x CR2450
Inner Protection Lens: PL-5003
Minimum TIG Welding Current: >3A
Maximum TIG Welding Current: 350A

Standards
CE Classification: 1/1/1/2

Replacement Lenses
Outer Replacement lens (1482)
Inner Replacement lens (3021)
