Chieftec 500W PSU

Chieftec 500W CTG-500-80p

General characteristics Chieftec�CTG-500-80P 500W Power: 500 W Standard: ATX12V 2.3 PFC: active Cooling system: 1 fan (120 mm) Connectors Chieftec�CTG-500-80P 500W Type of connector for the motherboard: 24 pin Number of connectors 4-pin CPU: 1 Number of connectors 8-pin CPU: 1 Number of connectors 6-pin PCI-E: 2 Number of connectors 15-pin SATA: 6 Number of connectors 4-pin IDE: 3 Number of connectors 4-pin Floppy: 1 Current strength Chieftec�CTG-500-80P 500W Current for the +3.3 V: 24 A Current on The +5 V: 20 A The current on the +12V line 1: 20 A The current on the +12V line 2: 20 A Current line -12: 0.3 A Current on The +5 V Standby: 2.5 A Additional information Chieftec�CTG-500-80P 500W Overvoltage protection: Yes Overload protection: Yes Short circuit protection: Yes Dimensions (HxWxD): 87x150x140 mm Features: 80 PLUS certified only for 230V - Source here https://mobilespecs.net/
