Minidsp Ddrc-24

Mini DSP DDRC-24
Dirac Live (built in)

- Condition: Good, working. fully functional.

- Comes with power adapter and usb cable. Additionally, an extra SPDIF out, with supporting converter box, to use MiniDSP with other DACs if you wish.

- Dirac Live license is linked to Minidsp. All you have to do is: create a user account @ MiniDsp and I will forward your info to them for the license transfer.

- Collection/Inspection possible in Ashbourne.

- Paypal/Revolut accepted.

DDRC-24, a USB DAC+DSP Digital Room Correction processor powered by Dirac Live in a tiny form factor

miniDSP introduces the DDRC-24, the world’s smallest Dirac Live® hardware processor.
Dirac Live®, the world’s premier room correction solution, is now available in an unbelievably compact hardware unit.
Powered by a 400 MHz Analog Devices SHARC processor, the DDRC-24 retains the 4-channel output of its sister unit, the miniDSP 2x4 Hd, in order to allow applications like subwoofer integration or even 2-way loudspeakers together with Dirac Live® room correction in a single tiny hardware platform. The matrix mixer and crossover functionality is accessed and programmed with miniDSP’s easy-to-use interface software. An all in one unit with USB DAC + Dirac Live Room Correction + Speaker processing.

I/O capabilities get an upgrade too, with the addition of USB audio streaming up to 192 kHz and a TOSLINK digital input. The miniDSP DDRC-24 will find application in full-sized hifi and home theater systems, on desktops, in cars, in recording studios anywhere a compact, powerful room correction processor is needed.

Features

ADSP21489 400MHz Sharc DSP floating point engine
XMOS Xcore200 for USB control and bidirectional audio streaming
24 bit ADC/DAC resolution
Dirac Live 3.x for miniDSP with 4 presets, fully configurable target curve
Unbalanced inputs switchable with a jumper between 4Vrms and 2Vrms
Toslink digital input
Unbalanced outputs: Max 2Vrms
USB Audio Class 2 Audio streaming with ASIO drivers, driverless under MAC OSx
4 preset configuration, recallable via IR, Software
Wifi/Alexa voice control via WI-DG accessory

No offers under the asking price
