HT Instruments Digital Power Clamp HT9012, 600A

“ Brand New in Box ” (66019)

1 x available in stock - rrp €150
__________________

Collection is available in the Kilkenny Area
or
Postage is available for €6 extra.
Shipping Nationwide: 1-2 working days
__________________

Product Description >>>

Professional clamp meter HT9012 has been designed to measure AC current up to 600A and AC/DC voltage up to 1000V to reach CAT IV 600V and CAT III 1000V in compliance with standard IEC/ EN61010-1.

Digital AC Clamp 600A 2000 points CAT IV

AC current up to 600A
DC/AC voltage up to 1000V
“Voltsense” feature for AC voltage detection
Resistance
Continuity test with buzzer
Manual/Autorange
Data HOLD
MAX
Backlight
AutoPower OFF

AC clamp meter up to 600A, 6000 points - CAT IV
HT9012 professional clamp is designed for AC current measurement up to 600A, and DC/AC voltage for achieve safety CAT IV 600V according to IEC/EN61010-1 safety standard. The model have a LCD display with backlight to more easy reading in critical environments. The model perform also resistance and continuity test measurements. The Autopower OFF feature is also available for this AC clamp meter in order to preserve it’s internal battery charge.

Size 215(L) x 74(La) x 43(H)mm
Weight (including battery) 285g
Max conductor size 30mm
Supply
Battery type 1 battery 9V NEDA 1604 IEC 6F22 JIS 006P.
Auto power OFF about 15 minutes of idleness
Display
Characteristics 3½ LCD (max 2000 counts), decimal point, unit symbol indication and backlight
Sample rate 2 times/sec
Conversion mode mean value
Climatic conditions
Reference temperature 25°C ± 5°C
Operating temperature 5 ÷ 40 °C
Operating humidity <80%RH
Storage temperature -20 ÷ 60 °C
Storage humidity <80%RH
Reference Standards
Comply with IEC/EN 61010-1
Insulation double insulation
Pollution Level 2
For inside use, max height 2000m
Installation category CAT III 600V, CAT III 1000V to ground
