Circutor 2-pole Differential Switch REC4 40A-4P-30M

1 x available in stock (70)

Collection is available in the Kilkenny Area
or
Postage is available for €6 extra.

Product Description >>>

The new REC4 represents an evolution of its REC3 predecessor in terms of size, maintaining all its features, the equipment now takes up a space of only 3 modules, which means that it can be installed without any hassle on new or existing electrical frames.

It also becomes the ideal solution for frames with limited space, replacing the standard differential protection (2 modules) and the magneto. Thermal (2 modmod) by the REC4 (3 modules) and a single-pole magnetothermic (1 module), also called DPN, in this way it is achieved to incorporate the automatic reconnection by taking up the same space, avoiding expansions of the electrical frame, REC4 additionally counts with the possibility of override the reconnection, by selecting manual or automatic mode, sealing it to prevent its manipulation during labelling. maintenance or Once in operation, once installed, it has LED indicators to check its status (ON/OFF/RECONNECTION) at all times, in a quick and visual way, to ensure the total protection of people, the device features an isolation protection system, which disables the automatic reconnection in case there is a direct contact during handling, avoiding any damage during its commissioning or in work. maintenance.

Installation It is really simple, as its compact size allows it to be placed as a differential current, and the user does not need to make any type of connection between the switch and the motor, as it is completely integrated into its surrounding, technical characteristics. Protection Type: Class A, Sensitivity: 30 mA, Trigger Delay: Instant, Rated Current: 40A, Number of Poles: 4 Pole, TS. Push Button Built-in in the switch, reset: mechanism in the front of the engine that allows ON/OFF; associated cutting element: differential switch, reconnection mode: time, number of reconnections: 3 reconnections, time between reconnections: 3, 20, 180 seconds, zero setting time of reconnections: 10, 20, 60. seconds.

Reconnection system: Mechanism in the front of the engine that allows ON/OFF, sealable, electrical characteristics. Number of poles/operating voltage: 2 poles/230 Vc,A, auxiliary supply: 230 Vc,A, +-20% 50/60Hz,output contacts of relays: 250 Vc. A, 130 mA,Operating temperature: -25ºC,,+55ºC,Chemical features: Fixation: DIN rail 46277 (EN 50022), Dimensions: 3 modules, Weight: 295 g, Protection class: IP20, Standards: IEC 61008-1, EN
