From 1981 Tuner Philips - 22AH103, in exelent condition.
Specifications:
First production year: 1981
Broadcast ranges: FM: 87.5 – 108 MHz. MW: 187 – 577m. LW: 870 – 2000m.
FM sensitivity: 0.9 µV
Total harmonic distortion mono/stereo: 0.25%
Frequency range (LF): 20 – 15,000 Hz -3dB
Capture Ratio (1 mV input): 2.5 dB
Selectivity (100 µV input): 62 dB
Signal-to-noise ratio 1 mV 75 kHz swing: 70 dB
Pilot tone suppression: 60 dB
Channel separation: 38 dB
AM suppression: 50 dB
MF suppression: 75 dB
Image suppression: 42 dB
Away-from-selectivity: 65 dB
Muting threshold: 2 – 5 µV
AM sensitivity at 26 dB signal-to-noise ratio: 90 µV
Selectivity: 36 dB
MF suppression: 65 dB
Image suppression: 40 dB
Dimensions: 100 x 450 x 337 mm
