Parkside 3/8" Quick-Release Ratchet

Parkside 3/8" Quick-Release Reversible Ratchet

Key Specifications

Drive Size: 3/8" (10 mm) square drive with spring-loaded ball detent

Mechanism: 72-tooth fine gear system (5° return angle)

Rotation Control: Switch lever for forward/reverse (clockwise and counter-clockwise)

Socket Release: Push-button quick-release mechanism

Total Length: ~200 mm

Weight: ~280 – 300 g

Materials & Construction

Body / Head: Chrome-Vanadium Steel (Cr-V), satin/matte chrome finish

Internal Pawl / Gears: Hardened chrome-molybdenum or carbon tool steel

Handle: Ergonomic 2-component dual-density polymer (soft-grip TPR / polypropylene)

Accessory Port: Integrated lanyard/hanging hole at the base of the handle

Usage Parameters

Max Recommended Torque: ~150 – 200 Nm (standard manual tightening/loosening for 3/8" Cr-V mechanisms)

Standard Compliance: Built according to DIN / ISO specifications for manual square drive ratchets
